Industrial pallet racks can easily store large individual items and palletized goods, providing a effective storage system that can be widely used in warehouses and factory environments.
The key to a successful storage operation is an effective storage layout, which contains enough storage capacity to meet the demand during busy periods, then enhance profits. Our standard pallet racking system provides a cost effective way to store large amounts of inventory in a warehouse.
Selective pallet racking is the most commonly and popular heavy duty warehouse storage racking system. Heavy duty pallet racking system can store goods of various specifications and sizes. Its size is flexible and can be changed according to the pallet and product, thus greatly increasing the storage capacity of the warehouse.
The forklift can directly access the individual pallets you need to load or unload. This makes the transportation process fast and convenient. Inventory management is also very simple.
Teardrop Hole
Rhombus-shaped Hole
Double-locking structure: After the hooks are inserted into the column holes, they are locked again with bolts. To prevent the crossbeam from falling off due to impact or vibration.
Stable Construction: Horizontal supports and diagonal braces are installed between the uprights every 2-3 layers to form a stable triangular structure and prevent the shelves from tipping over.
| Feature | Specifications |
|---|---|
| Material | Carbon steel Q235b, or customizable according to needs. |
| Load Capacity | Typically 1,000 kg to 3,000 kg per level |
| Rack Height | Customizable, typically 2000mm to 12000mm or more |
| Beam Length | Typically 2,000mm to 3,500mm, adjustable |
| Rack Depth | 1,000mm to 1,500mm |
| Forklift Access | Double-deep forklift required for rear pallet access |
| Aisle Width | Typically 2.5m to 3.5m (optimized for reach trucks) |
| Safety Features | Anti-collapse bars, end stops, locking pins, impact protection |
| Finish | Powder-coated or galvanized |
| Adjustability | Beams adjustable in 50mm/75mm increments |
Cargo Securing: Steel strapping ties and ropes are used to secure the shelving components. Heavy loads are reinforced with multiple layers for stability.
Protection: Shelves are wrapped in plastic film to prevent collisions. Shock-absorbing devices protect the structure and coating.
Weatherproofing: Goods are covered with high-quality waterproof tarpaulins and desiccants to keep them rainproof and rustproof.
Founded in 2009, we are a professional manufacturer integrating the R&D, design, production, and installation of modern logistics technologies. Recognized as a specialized, innovative, and high-tech enterprise, the company boasts strong technical expertise and advanced equipment such as cold-rolling lines, automated powder coating lines, and automatic continuous punching lines.
Our annual production capacity exceeds 20,000 tons. Product portfolio includes pallet racking, heavy-duty racking, mezzanine racking, cantilever racking, and more.
