Fangding Rack
1 / 5
The surface is treated with electrostatic spraying, offering advantages such as corrosion resistance, rust prevention, and a long service life.
Utilizing a high-specification C-shaped steel double-beam welded structure, it boasts superior bending strength compared to ordinary single beams.
Made of cold-formed steel plate with 21 folds for stronger load-bearing capacity. The surface features evenly distributed diamond-shaped or teardrop-shaped adjustable holes.
Diamond-shaped holes: 75mm fixing hole spacing; Teardrop-shaped holes: 50mm fixing hole spacing. Customers can adjust the height of each layer as needed.
After the hooks are inserted into the column holes, they are locked again with bolts. This effectively prevents the crossbeam from falling off due to impact or vibration.
Horizontal supports and diagonal braces are installed every 2-3 layers of uprights, forming a triangular stability structure to prevent the shelving from tipping over.
High-strength steel anti-collision upright protectors are installed at column bottoms and passageway sides, fixed to the ground with expansion bolts to absorb forklift impact, preventing column deformation and cargo collision damage.
| Specification | Details |
|---|---|
| Type | Heavy-Duty Selective Pallet Rack |
| Material | Q235B Steel, Cold Rolled Steel |
| Certifications | CE, ISO9001, GOST |
| Color | Blue, Orange, Customizable |
| Beam Length | Customizable, Typically 2,000mm to 3,500mm |
| Rack Depth | Customizable, 1,000mm to 1,500mm |
| Rack Height | Customizable, typically 2,000mm to 12,000mm+ |
| Column Size | Customizable (e.g., 100x70, 90x80, 90x70, 55x47mm) |
| Aisle Width | Typically 2.5m to 3.5m |
| Adjustability | Beams adjustable in 50mm/75mm increments |
| Environmental | Normal Temperature or Cold Room (Max -40C) |
Comparison of warehouse capacity improvement before and after:
Our Warehouse
Our Equipment
A: We are a manufactory for storage racks.
A: Qingdao port, or we can arrange shipment according to your needs.
A: For normal temperature warehouses, we use carbon steel Q235b. For cold storage (minus 18°C or lower), we adopt Q345D or other customized steel types.
A: No, we do not have an MOQ requirement for most of our products. Typically, a 1*20ft container order is recommended for cost efficiency.
A: T/T and L/C are welcomed.
A: It depends on the order quantity and racking types, normally is 15 to 30 days after receipt of the deposit.
